Computery Stuff

This puzzle map will teach you circuit logic and sequential logic. Your goal is to light up the lamp at the end of the room. This map introduce a new type of mechanism called "Bluestone". Bluestone can be either Active or Desactive. You can change it stat by pressing buttons.

Featuring a few logic gate:

• The AND Gate: Left and Right Signal must be Active for it to output an Active Signal
• The NOT Gate: Inverse the Singal
• The OR Gate: Left or Right Signal must be Active for it to output an Active Signal
• The XOR Gate: Left or Right (But not both) Signal must be Active for it to output an Active Signal
• The Multiplexer: Output the same as Left if bottom is OFF Otherwise Output the same as Right

Featuring a few memory gate:

• The D-Latch: Output The same as It Right Input If the Left Input is On. Otherwise the Output Doesn't change
• The D-Flip-Flip: Output The same as It Right Input If the Left Goes from OFF to ON. Otherwise the Output Doesn't change
